This device is designed for the terminal sterilization of packaged medical devices such as surgical instrumentation sensitive to heat and humidity. Read more
PL 130 is a low-temperature sterilization system with a chamber capacity of up to 148 litres / 5.21 cu ft. Instruments with lumen with a maximum length of up to 2200 mm / 86.6″ and a minimum diameter of up to 0,5 mm / 0.02″. Vaporized hydrogen peroxide sterilization with SteelcoPro PL sterilizing agent is safe, fast, and environmentally friendly – operating with low pressure and low temperature for protecting instruments and reducing energy consumption.
Available as single door or double door versions, it is equipped with an automatic space-saving sliding door. PL 130 is controlled by a PLC digital microprocessor with a 10″ color touch screen HMI. Loading and unloading operations can be done at an ergonomic height. The loading height is ergonomically placed at 920 mm / 36.22″.
| Specifications | Descriptions |
|---|---|
| Single Door Version Overall Dimensions WxDxH 770 x 1040 x 1685 mm 30.3” x 40.94” x 66.34” Chamber Volume ~143 lt / 5,05 cu ft Double Door Version Overall Dimensions WxDxH 770 x 1070 x 1685 mm 30.3” x 42.13” x 66.34” Chamber Volume ~148 lt / 5.21 cu ft | The sliding door solution of the PL 130 allows reducing space in the clean area in favor of packaging and easier loading/unloading of the instruments. Excellent penetration into hollow instruments: Lumens: Ø ≥ 0.5 length ≤ 2200 mm, with single, double, and triple channels. |
